INSTECH DongHwa Control

Micro Process Based Indicator

Indicator   | Strain Gauge Transducers

SM-110N     | for strain gauge

  • 적용가능 센서 출력: 1~3 mV/V (DIP S/W조정)
  • 센서용 전원: 10Vdc, 5Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 16 bit
  • Nonlinearity: ±0.02% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)

DATASHEET  사용설명서

SM-11EN     | for strain gauge (RS-485 통신기능)

  • 적용가능 센서 출력: 1~3 mV/V (DIP S/W조정)
  • 센서용 전원: 10Vdc, 5Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 16 bit
  • Nonlinearity: ±0.02% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET  사용설명서

SM-11RN     | for strain gauge (RS-232C 통신기능)

  • 적용가능 센서 출력: 1~3 mV/V (DIP S/W조정)
  • 센서용 전원: 10Vdc, 5Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 16 bit
  • Nonlinearity: ±0.02% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET  사용설명서

SM-11HN     | for strain gauge (High Speed Sampling)

  • 적용가능 센서 출력: 1~3 mV/V (DIP S/W조정)
  • 센서용 전원: 10Vdc, 5Vdc (optional)
  • A/D Sampling Speed: 4000회/sec
  • A/D 분해능: 16 bit
  • D/A 분해능: 16 bit
  • Nonlinearity: ±0.05% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)

DATASHEET  사용설명서

SM-51EN     | for strain gauge (RS-485 통신기능, 24bit 분해능)

  • 적용가능 센서 출력: 1~3 mV/V (DIP S/W조정)
  • 센서용 전원: 10Vdc, 5Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 24 bit
  • Nonlinearity: ±0.05% / F.S
  • 최대문자 표시 범위: 99999~-9999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET

SM-51RN     | for strain gauge (RS-232C 통신기능, 24bit 분해능)

  • 적용가능 센서 출력: 1~3 mV/V (DIP S/W조정)
  • 센서용 전원: 10Vdc, 5Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 24 bit
  • Nonlinearity: ±0.05% / F.S
  • 최대문자 표시 범위: 99999~-9999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET

Indicator   | DC Voltage / Current Transducers

SM-210N     | for DC voltage/current Transducers

  • 적용가능 센서 출력: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • 센서용 전원: 10V, 24V (5~26V가변) or ±15Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 16 bit
  • Nonlinearity: ±0.02% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)

DATASHEET  사용설명서

SM-21EN     | for DC voltage/current (RS-485 통신기능)

  • 적용가능 센서 출력: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • 센서용 전원: 10V, 24V (5~26V가변) or ±15Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 16 bit
  • Nonlinearity: ±0.02% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET  사용설명서

SM-21RN     | for DC voltage/current (RS-232C 통신기능)

  • 적용가능 센서 출력: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • 센서용 전원: 10V, 24V (5~26V가변) or ±15Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 16 bit
  • Nonlinearity: ±0.02% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET  사용설명서

SM-21HN     | for DC voltage/current (High Speed Sampling)

  • 적용가능 센서 출력: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • 센서용 전원: 10V, 24V (5~26V가변) or ±15Vdc (optional)
  • A/D Sampling Speed: 4000회/sec
  • A/D 분해능: 16 bit
  • D/A 분해능: 16 bit
  • Nonlinearity: ±0.05% / F.S
  • 최대문자 표시 범위: ± 19999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)

DATASHEET  사용설명서

SM-61EN     | for DC voltage/current (RS-485 통신기능)

  • 적용가능 센서 출력: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • 센서용 전원: 10V, 24V (5~26V가변) or ±15Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 24 bit
  • Nonlinearity: ±0.05% / F.S
  • 최대문자 표시 범위: 99999~-9999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET

SM-61RN     | for DC voltage/current (RS-232C 통신기능)

  • 적용가능 센서 출력: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • 센서용 전원: 10V, 24V (5~26V가변) or ±15Vdc (optional)
  • A/D Sampling Speed: 15회/sec, 30회/sec, 120회/sec (선택가능)
  • A/D 분해능: 24 bit
  • Nonlinearity: ±0.05% / F.S
  • 최대문자 표시 범위: 99999~-9999
  • Analog Output: 0~±5V, 0~±10V, 1~5V, 4~20mA
  • Relay Output: High, Low 각 A,B 접점 (AC250V 5A)
  • 통신방법: 반 2중 비 동기 통신
  • 통신설정: 8 bit, No parity, 1 stop bit
  • 전송속도: 2400~19200 bps/sec

DATASHEET

Unit Calculator (환산표)
application (적용사례)

IAA100 Gain and Shunt Settings

Signal Conditioning Amplifier | Voltage Output, Current Output, Differential Input/Output

IAA100     | Analog Amplifier with Voltage Output

  • Full Bridge Strain Gage Signal Conditioning Voltage Amplifier
  • +/-5 VDC , +/-10 VDC , 5 VDC Offset DIP Switch
  • Up to 25 kHz Bandwidth , Detachable Screw Terminal Connectors , Metallic Enclosure , Integrated 35 mm DIN Clip

DATASHEET
MANUAL
Gain Setting Excel

IAA200     | Analog Amplifier with Current Output

  • Full Bridge Strain Gage Signal Conditioning Current Transmitter
  •  4-20 mA , 12 mA Offset DIP Switch
  • Up to 25 kHz Bandwidth , Detachable Screw Terminal Connectors , Metallic Enclosure , Integrated 35 mm DIN Clip

DATASHEET
MANUAL
Gain Setting Excel

IAA300     | Differential Strain Gauge Amplifier

  • Ultra Low Noise Signal Conditioning Differential Strain Gauge Voltage Amplifier , For Full Bridge
  • +/-5 VDC , +/-10 VDC
  • Up to 50 kHz Bandwidth , Screw Terminal Connectors , Red Powder Coated , Integrated DIN Clip

DATASHEET
MANUAL
Gain Setting Excel

Amplifier with USB Output | Digitally Configurable Amplifier with USB Output

IDA100     | Digitally Configurable Amplifier

  • High Speed & High Resolution Programmable Analog Amplifier w/ Greater Than 1 kHz Noise Rejection & Up To 4800 SPS USB Output
  • 0-10 VDC Analog Output
  • Powered By USB , Red Powder Coated Aluminum Enclosure, Integrated DIN Clip

DATASHEET
Quick Start Guide

4 Channel Summing Junction Box | Amplified Junction Box, Non-Amplified Junction Box

IAC200     | 2-4 Channel Summing Junction Box

  • Dip Switch Selectable Channels (2-4)
  • Individual Span Adjustment For All 4 Channels
  • IP65/NEMA 4X Rated Housing UV Stable 94V-2 Polycarbonate Material
  • Operating Temperature: 32° F to 158° F (0°C to 70°C)

DATASHEET
Quick Start Guide
Product FAQ

Display | Panel Mount, Handheld display

IHH500     | Intelligent Digital Handheld Display

  • mV/V , VDC , & mA Measurement
  • Analog Output , Alarm Relays , TEDS & USB Output , Only Power Supply Adapter is included
  • Keypad Options (Track/Hold, Peak/Valley Reset, Unit, Tare/ Gross, Shunt, Battery, Display, Menu)
  • USB Output, ASCII Stream Output

DATASHEET
Manual
Wiring Connection Examples

IPM650     | Intelligent Panel Mount

  • mV/V , VDC , Current Measurement
  • Analog Output , Alarm Relays , TEDS and USB Output
  • Keypad options (Track/Hold – Peak/Valley Reset – Unit – Tare/Gross-Shunt – Channel – Display-Menu)
  • Powers on when plugged in (QSH01633 Version)

DATASHEET
Manual
Quick Start Guide

USB Output Modules | High Resolution USB Output Module

USB220     | External USB Output Kit (mV/V input)

  • External USB Output Kit
  • 24 Bit Resolution , Up To 19 Bit Noise Free
  • For mV/V Inputs
  • Up to 4800 SPS , Red Powder Coated

DATASHEET
HyperTerminal Setup Guide
Troubleshooting Guide

USB320     | External USB Output Kit (Amplified Input (Voltage or Current))

  • External USB Output Kit
  • 24 Bit Resolution , Up To 19 Bit Noise Free
  • For Amplified Inputs (Voltage Only) or Amplified Inputs (Current Only)
  • Up to 4800 SPS

DATASHEET
HyperTerminal Setup Guide
Troubleshooting Guide

USB520     | External USB Kit (mV/V, amplified and encoder input)

  • External USB Output Kit
  • 24 Bit Resolution , Up To 19 Bit Noise Free
  • For Strain Gauge , Amplified , and Encoder Inputs
  • Up to 4800 SPS, Integrated DIN Clip

DATASHEET
HyperTerminal Setup Guide
Troubleshooting Guide

SENSIT     | Test and Measurement Software

Installation Guide
Quick Start Guide
Software Manual

Related Documents 링크 (Docs, DLL Examples, Programming Guide)
